The F3000 Shacman 12 Wheeler Cargo Truck uses FAG low resistance to maintain bearing technology synchronized with Europe. The independent lubricant system not only makes maintenance more convenient, but also reduce the overall fuel consumption.
The F3000 Shacman 12 Wheeler Cargo Truck structure conducts systemic topology optimization and applies high -intensity and multiple composite materials. Optimization of the F3000 Shacman engine and bridge, aluminum alloy gearbox and casting structure.
F3000 Shacman 12 Wheeler Cargo Truck Price in Nigeria
F3000 Shacman 12 Wheeler Cargo Truck Price in Nigeria
F3000 Shacman 12 Wheeler Cargo Truck Price in Nigeria
Brand: Shacman 12 wheeler truck price cargo truck
Drive model: Left or right driven hand, 8X4
Clutch: ∮430 diaphragm clutch
Gearbox Model: Fast Fuller RT11509C gearbox with 9 forward and 1 reverse
Propeller shaft: ∮180 contrite gear propeller shaft
Front axle: Man technology 7.5 tons
Rear suspension: inverted leaf spring with stabilizer
Steering Model: 8098 integral circuiting ball power steering
Ratio:22.2-26.2:1
Instrument panel: Combined instrument panel
Rear axle: Styre13 tons with hub reduction ratio 1:4.8
Chassis: Various width, front 940mm and rear 850mm
Cargo dimension Volume(mm): 9000X2326X500/800
Other: A/C, enlargement radiator, ABS
Shacman 12 wheeler truck price Engine
Engine model: Weichai WD12.375
Power(Kw/Hp): 276/375
Speed(r/min):2200
Idle speed(r/min):600-800
Max torque(N.m):1500
Stroke(mm):126/155
Displacement(L):11.596
Min.fuel consumption(g/Kw.h):≦198
Engine oil filling volume:39L
The thermostat opened at 82℃
Oil pump: P12
Type: mechanically control, diesel engine, 4-stroke,6-cylinder in line, inter-cooling and turbo-charging, euro-2 or emission standard
Shacman cargo truck Electrics
Starter: 7.8kw,24V
Alternator: 1.54kw(28V,70A)
Battery: 180AH
Shacman cargo truck Brakes
Running brake: Dual circuiting compressed air brake
Tyre: 12.00-20/12.00R20/12.00R22.5,13pcs
Cabin: Man F2000 flat head with two seats and one sleep with A/C
Parking brake: Rear wheel power spring brake
Auxiliary brake: Engine exhaust brake
Shacman cargo truck Dimension (mm)
Wheel base:4600+1350+1800
Front wheel track:2036
Rear wheel track:1860
Front overhang: 1525
Rear overhang: 3070
Overall length: 12025
Overall width:2490
Overall height: 3770
Approach angle: 20°
Departure angle: 11°
Fuel tank(L): 380L
Shacman 12 wheeler truck price Weight(Kg)
GVW:31000
Front axle loading capacity:7500X2
Rear axle loading weight: 13000X2
Performance
Max. running speed(km/h):96
Max. climbing capacity(%):20
Min. ground clearance(mm):318
Fuel consumption(L/100km):40
