Shaanxi x3000 concrete mixer truck is mainly composed of chassis, mixing tank, transmission system (drive device), hydraulic system, water supply system, feeding and discharging system, discharging trough, operating platform, operating system and protective equipment.
Shaanxi x3000 concrete mixer truck driving method is that the engine is the power source, and the power is taken from the power take-off at the rear end of the engine, and is transmitted to the variable piston hydraulic pump through the transmission shaft. The mixing tank is driven by the reducer to rotate.
The Shaanxi x3000 concrete mixer truck is mainly composed of chassis, mixing tank, transmission system (drive device), hydraulic system, water supply system, feeding and discharging system, discharging trough, operating platform, operating system and protective equipment.
Shaanxi X3000 Concrete Mixer Truck Cost Price for Sale in Nigeria
Shaanxi X3000 Concrete Mixer Truck Cost Price for Sale in Nigeria
Shaanxi X3000 Concrete Mixer Truck Cost Price for Sale in Nigeria
Brand: Shacman X3000 6x4 Mixer Truck
Cab Type: MAN X3000, lengthened flat roof
Logistics type: Concrete
Distance(km): ≤50
Road type: Paved roads
Drive: 6x4
Max weight(t): <35
Crusing speed/Max speed(km/h): 80
Road type: Paved roads
Loaded speed(km/h): 45~ 60
Vehicle model: SX5255GJB5R364C
Engine(km/h): ISM 345+PTO
Emission standard: EurolII
Displacement: 11.596L
Rated Output: 254kW
Max. torque: 1710N-m
Transmission: 9JS180
Clutch: 430
Frame: 850x300 ( 8+7 )
Front axle: MAN 7.5T
Rear axle: 16T MAN double reduction 5.262
Tire: 12.00R20
Front Suspension: Multi leaf springs
Rear Suspension: Multi leaf springs
Fuel: Diesel
Capacity of the fuel tank: 400L ( Aluminum shell )
Battery: 180Ah
Dimensions(LxWxH): 8275x 2495x3774
Volume ( m3 ): 9
Wheelbase: 3575+ 1400
Approach / Departure angle (): 20/18
Max.gadeabilty(%): 34
