Shacman F3000 Chassis Truck Equipment with Eaton AMT 10 -speed automatic transmission, 445/95R25 large -size engineering tires, independent wind, fuel heating device, electric heating rearview mirror, adapting to bad road conditions, Shacman F3000 CHASSIS TRUCK power is strong, Good mobility.
In addition, at the front end of the chassis, both sides of the chassis, and the rear suspension of the chassis at the Shacman F3000 CHASSIS TRUCK chassis, there is a special device installation interface, and the chassis modification adaptability is good.
Shacman F3000 Chassis Truck | Shacman Heavy Duty Truck Price
Shacman F3000 Chassis Truck | Shacman Heavy Duty Truck Price
Shacman F3000 Chassis Truck | Shacman Heavy Duty Truck Price
Shacman F3000 Chassis Truck | Shacman Heavy Duty Truck Price
Brand: shacman f3000 price
Drive model: Left or right driven hand, 10x6
Clutch: ∮430 diaphragm clutch
Gearbox Model: Fast Fuller RT11509C gearbox with 9 forward and 1 reverse
Propeller shaft: ∮180 contrite gear propeller shaft
Front axle: Man technology 7.5 tons
Rear suspension: inverted leaf spring with stabilizer
Steering Model: 8098 integral circuiting ball power steering
Ratio:22.2-26.2:1
Instrument panel: Combined instrument panel
Rear axle: Styre13 tons with hub reduction ratio 1:4.8
Chassis: Various width, front 940mm and rear 850mm
Cargo dimension Volume(mm): 9000X2326X500/800
Other: A/C, enlargement radiator, ABS
Shacman f3000 price Engine
Engine model: Weichai WD12.375
Power(Kw/Hp): 276/375
Speed(r/min):2200
Idle speed(r/min):600-800
Max torque(N.m):1500
Stroke(mm):126/155
Displacement(L):11.596
Min.fuel consumption(g/Kw.h):≦198
Engine oil filling volume:39L
The thermostat opened at 82℃
Oil pump: P12
Type: mechanically control, diesel engine, 4-stroke,6-cylinder in line, inter-cooling and turbo-charging, euro-2 or emission standard
Shacman price Electrics
Starter: 7.8kw,24V
Alternator: 1.54kw(28V,70A)
Battery: 180AH
Shacman price Brakes
Running brake: Dual circuiting compressed air brake
Tyre: 12.00-20/12.00R20/12.00R22.5,13pcs
Cabin: Man F2000 flat head with two seats and one sleep with A/C
Parking brake: Rear wheel power spring brake
Auxiliary brake: Engine exhaust brake
Shacman chassis truck Dimension (mm)
Wheel base:4600+1350+1800
Front wheel track:2036
Rear wheel track:1860
Front overhang: 1525
Rear overhang: 3070
Overall length: 12025
Overall width:2490
Overall height: 3770
Approach angle: 20°
Departure angle: 11°
Fuel tank(L): 380L
Shacman chassis truck Weight(Kg)
GVW:31000
Front axle loading capacity:7500X2
Rear axle loading weight: 13000X2
Shacman chassis truck Performance
Max. running speed(km/h):96
Max. climbing capacity(%):20
Min. ground clearance(mm):318
Fuel consumption(L/100km):40
